Mac keyboard shortcuts By pressing certain key combinations, you can do things that normally need a mouse, trackpad, or other input device. To use a keyboard shortcut, press and hold one or more modifier keys and then press the last key of the shortcut.

Boot Camp Control Panel User Guide

The keyboards on some portable Mac computers provide backlighting, so that the keys are visible in low light conditions. If keyboard backlighting is on, the keys light up automatically whenever the ambient light is low.

Automatically turn off keyboard backlighting when your computer is idle

1. In Windows on your Mac, click in the right side of the taskbar, click the Boot Camp icon , then choose Boot Camp Control Panel.

2. If a User Account Control dialog appears, click Yes.

3. Click Keyboard.

4. Drag the “Turn off keyboard backlight when computer is not used for” slider.

Change keyboard backlighting

• In Windows on your Mac, press the F5 key to decrease keyboard backlighting, or press the F6 key to increase keyboard backlighting. You may need to hold down the Fn key as you press the F5 or F6 key.

If the F5 and F6 keys don’t adjust backlighting, make sure you have the latest Windows support software installed. See the Apple Support article Download and install Windows support software on your Mac.

Choose your model

1. From the Apple () menu, choose About This Mac.
2. Click More Info.
3. Select Hardware from the Contents list.
4. Find 'Number of Processors' under Hardware Overview. The quad-core and 6-core Mac Pro have one CPU and the 8-core and 12-core Mac Pro have two CPUs.

Applicable models

Mac Pro (Mid 2012), Quad-core
Mac Pro (Mid 2012), 6-core
Mac Pro (Mid 2012), 12-core

Memory specifications

Mac Pro (Mid 2012) computers have these memory specifications:

Removing or installing memory

Step 1: Determine which Mac Pro you have

1. Choose Apple (), then About This Mac from the upper-left menu bar.
2. Click More Info.
3. Select Hardware from the Contents list.
4. Find Number Of Processors in Hardware Overview. The quad-core and 6-core Mac Pro have one CPU and 12-core Mac Pro have two CPUs.

Step 2: Remove the side panel

1. Before you open your Mac Pro, shut it down by choosing Shut Down from the Apple () menu.
   Note: Always shut down your Mac Pro before opening it to avoid damaging its internal components or the components you want to install. Do not open your Mac Pro or attempt to install items inside it while it is on.
2. Wait 5 to 10 minutes to allow the internal components of your Mac Pro to cool.
   Warning: Let your Mac Pro cool down before you touch the internal components, which may be very warm.
3. Touch the metal on the outside of your Mac Pro to discharge any static electricity.
   Note: Always discharge static before you touch parts or install components inside your Mac Pro. To avoid generating static, don't move around the room until you finish installing the cards, memory, or internal storage device and replace the side panel.
4. Unplug all the cables and the power cord from your Mac Pro.
   Note: To avoid damaging internal components or the components you want to install, always unplug your Mac Pro. Don't attempt to install items while it's plugged in.
5. Hold the side panel and lift the latch on the back.
6. Remove the side panel by pulling the top away from your Mac Pro and lifting up.Important: Hold the side panel securely wile you remove it.

Step 3: Install the memory

In a Quad-Core or 6-Core Mac Pro (Mid 2012):​

1. Push the latches on the processor tray until they partially open.
2. Pull the latches until they open all the way and release the processor tray.
3. Remove the processor tray and lay it on a soft, clean cloth on the desk or work surface, to protect the tray and avoid scratching the work surface.
4. If you are installing equal-size DIMMs (all 2 GB or all 4 GB) in your Mac Pro, Apple recommends that you fill the slots in the order listed in the table.

   If you have	Fill these slots
   Two DIMMs	1 and 2
   Three DIMMs	1, 2, and 3
   Four DIMMs	1, 2, 3, and 4 (all)

   Note: If you install different sized DIMMs in your Mac Pro, follow the order in the table above. If the DIMM configuration you install doesn't provide optimized performance, the Memory Slot Utility should appear onscreen and recommend an improved configuration. To use the utility again, go to /System/Library/CoreServices/Memory Slot Utility.

5. Open the ejectors on DIMM slots 1, 2, and 3 and push them out to the sides. Remove the DIMMs from the slots.
6. Install the DIMMs by aligning them in the DIMM slots and pushing both ends of the DIMM down until the tabs are vertical and the ejectors snap into place.

   Note: To avoid damaging the DIMM, hold it by the corners and don't touch the gold connectors or other components.

7. Reinstall the processor tray, pushing it in until the latches are at a 45-degree angle.
8. Push the latches all the way in to close them and seat the processor tray.

In a Quad-Core or 6-Core Mac Pro (Mid 2012):​​

1. Push the latches on the processor tray until they partially open.
2. Pull the latches until they open all the way and release the processor tray.
3. Remove the processor tray and lay it on a soft, clean cloth on the desk or work surface to protect the tray and avoid scratching the work surface.
4. If you install equal-size DIMMs (for example, all 2 or 4 GB DIMMs) in your Mac Pro, Apple recommends that you fill the slots in the order listed in the table.

   If you have	Fill these slots	Fill these slots
   Two DIMMs	1 and 2
   Three DIMMs	1, 2, and 3
   Four DIMMs	1, 2, 5, and 6
   Six DIMMs	1, 2, 3 and 5, 6, 7
   Eight DIMMs	1, 2, 3, 4, and 5, 6, 7, 8 (all)

   Note: If you install different-size DIMMs in your Mac Pro, follow the order in the table. If the DIMM configuration you install doesn't provide optimized performance, the Memory Slot Utility appears onscreen and recommends an improved configuration.

5. To use the utility again, go to /System/Library/CoreServices/Memory Slot Utility.
6. Install the DIMMs by aligning them in the DIMM slots and pushing both ends of the DIMM down until the tabs are vertical and the ejectors snap into place.

   Note: To avoid damaging the DIMM, hold it by the corners and don't touch the gold connectors or other components.

7. Reinstall the processor tray, pushing it in until the latches are at a 45-degree angle.
8. Push the latches all the way in to close them and seat the processor tray.

Step 4: Replace the side panel

Note: Always replace the side panel after installing components. Your Mac Pro won't operate properly without the side panel in place.

Important: When you replace the side panel, make sure the latch is up. Hold the side panel securely so it stays in place as you push the latch down.

1. Hold the side panel against your Mac Pro and push the latch down to secure the side panel.
2. You can attach a lock or cable through the metal loop to secure your Mac Pro. Flip the lock tab down before you close the latch.

Note: Always replace the side panel after installing components. Your Mac Pro won't operate properly without the side panel in place.

Important: When you replace the side panel, make sure the latch is up. Hold the side panel securely so it stays in place as you push the latch down.

1. Hold the side panel against your Mac Pro and push the latch down to secure the side panel.
2. You can attach a lock or cable through the metal loop to secure your Mac Pro. Flip the lock tab down before you close the latch.

Applicable models

Mac Pro (Mid 2010), Quad-core
Mac Pro (Mid 2010), 6-core
Mac Pro (Mid 2010), 8-core
Mac Pro (Mid 2010), 12-core

Memory specifications

The Mac Pro (Mid 2010) computers have these memory specifications:

Removing or installing memory

Step 1: Determine which Mac Pro you have

1. Choose Apple (), then About This Mac from the upper-left menu bar.
2. Click More Info.
3. Select Hardware from the Contents list.
4. Find Number Of Processors in Hardware Overview. The quad-core and 6-core Mac Pro have one CPU and the 8-core and 12-core Mac Pro have two CPUs.

Step 2: Remove the side panel

1. Before you open your Mac Pro, shut it down by choosing Apple (), then Shut Down.

   Note: Always shut down your Mac Pro before opening it to avoid damaging its internal components or the components you want to install. Do not open your Mac Pro or attempt to install items inside it while it is on.

2. Wait 5 to 10 minutes to allow the internal components of your Mac Pro to cool.

   Warning: Let your Mac Pro cool down before you touch the internal components, which may be very warm.

3. Touch the metal on the outside of your Mac Pro to discharge any static electricity.

   Note: Always discharge static before you touch parts or install components inside your Mac Pro. To avoid generating static, don't move around the room until you finish installing the cards, memory, or internal storage device and replace the side panel.

4. Unplug all the cables and the power cord from your Mac Pro.

   Note: To avoid damaging internal components or the components you want to install, always unplug your Mac Pro. Don't attempt to install items while it's plugged in.

   Hold the side panel and lift the latch on the back.

5. Remove the side panel by pulling the top away from your Mac Pro and lifting up.

   Important: Hold the side panel securely wile you remove it.

Step 3: Install the memory

In a Quad-Core or 6-Core Mac Pro (Mid 2010)​

1. Push the latches on the processor tray until they partially open.
2. Pull the latches until they open all the way and release the processor tray.
3. Remove the processor tray and lay it on a soft, clean cloth on the desk or work surface, to protect the tray and avoid scratching the work surface.
4. If you are installing equal-size DIMMs (all 1 GB or all 2 GB) in your Mac Pro, Apple recommends that you fill the slots in the order listed in the table.

   If you have	Fill these slots
   Two DIMMs	1 and 2
   Three DIMMs	1, 2, and 3
   Four DIMMs	1, 2, 3, and 4 (all)

   Note: If you install different sized DIMMs in your Mac Pro, follow the order in the table above. If the DIMM configuration you install doesn't provide optimized performance, the Memory Slot Utility should appear onscreen and recommend an improved configuration. To use the utility again, go to /System/Library/CoreServices/Memory Slot Utility.

5. Open the ejectors on DIMM slots 1, 2, and 3 and push them out to the sides. Remove the DIMMs from the slots.
6. Install the DIMMs by aligning them in the DIMM slots and pushing both ends of the DIMM down until the tabs are vertical and the ejectors snap into place.

   Note: To avoid damaging the DIMM, hold it by the corners and don't touch the gold connectors or other components.

7. Reinstall the processor tray, pushing it in until the latches are at a 45-degree angle.
8. Push the latches all the way in to close them and seat the processor tray.

In an 8-Core or 12-Core Mac Pro (Mid 2010)​

1. Push the latches on the processor tray until they partially open.
2. Pull the latches until they open all the way and release the processor tray.
3. Remove the processor tray and lay it on a soft, clean cloth on the desk or work surface to protect the tray and avoid scratching the work surface.
4. If you install equal-size DIMMs (for example, all 1 or 2 GB DIMMs) in your Mac Pro, Apple recommends that you fill the slots in the order listed in the table.

   If you have	Fill these slots	Fill these slots
   Two DIMMs	1 and 2
   Three DIMMs	1, 2, and 3
   Four DIMMs	1, 2, 5, and 6
   Six DIMMs	1, 2, 3 and 5, 6, 7
   Eight DIMMs	1, 2, 3, 4, and 5, 6, 7, 8 (all)

   Note: If you install different-size DIMMs in your Mac Pro, follow the order in the table. If the DIMM configuration you install doesn't provide optimized performance, the Memory Slot Utility appears onscreen and recommends an improved configuration.

5. To use the utility again, go to /System/Library/CoreServices/Memory Slot Utility.
6. Install the DIMMs by aligning them in the DIMM slots and pushing both ends of the DIMM down until the tabs are vertical and the ejectors snap into place.

   Note: To avoid damaging the DIMM, hold it by the corners and don't touch the gold connectors or other components.

7. Reinstall the processor tray, pushing it in until the latches are at a 45-degree angle.
8. Push the latches all the way in to close them and seat the processor tray.

Step 4: Replace the side panel

Note: Always replace the side panel after installing components. Your Mac Pro won't operate properly without the side panel in place.

ListenDownload The Outsiders Audiobook – By S. 7 months ago / The Outsider Audiobook is a novel, written by S.E. Hinton, and was first published in 1967 by Viking Press. Hinton was only 18 when the novel was published. Listen To The Outsiders Audiobook Free Complete which includes all the chapters of the book. The outsiders study guide free download - Audio Army Study Guide, Art History Study Guide, World Religions Study Guide, and many more programs. Free audio the outsiders mrs lewis. The Outsiders is a dramatic and enduring work of fiction that laid the groundwork for the YA genre. Hinton's classic story of a boy who finds himself on the outskirts of regular society remains as powerful today as it was the day it was first published. The Outsiders is a coming-of-age novel by S. Hinton, first published in 1967 by Viking Press. Hinton was 15 when she started writing the novel but did most of the work when she was 16 and a junior in high school.

Important: When you replace the side panel, make sure the latch is up. Hold the side panel securely so it stays in place as you push the latch down.

1. Hold the side panel against your Mac Pro and push the latch down to secure the side panel.
2. You can attach a lock or cable through the metal loop to secure your Mac Pro. Flip the lock tab down before you close the latch.

Applicable models

Mac Pro (Early 2009), Quad-core
Mac Pro (Early 2009), 8-core

Memory specifications

The Mac Pro (Early 2009) computers have these memory specifications:

Removing or installing memory

Step 1: Determine which Mac Pro you have

1. Choose Apple (), then About This Mac from the upper-left menu bar.
2. Click More Info.
3. Select Hardware from the Contents list.
4. Find Number Of Processors in Hardware Overview. The quad-core and 6-core Mac Pro have one CPU and the 8-core Mac Pro has two CPUs.

Step 2: Remove the side panel

1. Before you open your Mac Pro, shut it down by choosing Apple (), then Shut Down.

   Note: Always shut down your Mac Pro before opening it to avoid damaging its internal components or the components you want to install. Do not open your Mac Pro or attempt to install items inside it while it is on.

2. Wait 5 to 10 minutes to allow the internal components of your Mac Pro to cool.

   Warning: Let your Mac Pro cool down before you touch the internal components, which may be very warm.

3. Touch the metal on the outside of your Mac Pro to discharge any static electricity.

   Note: Always discharge static before you touch parts or install components inside your Mac Pro. To avoid generating static, don't move around the room until you finish installing the cards, memory, or internal storage device and replace the side panel.

4. Unplug all the cables and the power cord from your Mac Pro.

   Note: To avoid damaging internal components or the components you want to install, always unplug your Mac Pro. Don't attempt to install items while it's plugged in.

5. Hold the side panel and lift the latch on the back.
6. Remove the side panel by pulling the top away from your Mac Pro and lifting up.

   Important: Hold the side panel securely wile you remove it.

Step 3: Install the memory

In a Quad-Core Mac Pro (Early 2009)​

Ati 3650 hd drivers for mac. ATI MOBILITY RADEON 3650 DRIVERS FOR MAC DOWNLOAD - You may use the Software only on Dell computers or devices, with the exception of mobile device application software specifically designed by Dell to be. ATI HD 3650 DRIVERS FOR MAC - The following benchmarks stem from our benchmarks of review laptops. The audio is poor or missing. World in Conflict - Benchmark Mobility Radeon HD compare. Intel Core 2 Duo T, 17', 3. Unable to add item to List. There was a problem filtering reviews right now. Uploader: Tazahn Date Added: 5 December 2016 File Size.

1. Push the latches on the processor tray until they partially open.
2. Pull the latches until they open all the way and release the processor tray.
3. Remove the processor tray and lay it on a soft, clean cloth on the desk or work surface, to protect the tray and avoid scratching the work surface.
4. If you are installing equal-size DIMMs (all 1 GB or all 2 GB) in your Mac Pro, Apple recommends that you fill the slots in the order listed in the table.

   If you have	Fill these slots
   Two DIMMs	1 and 2
   Three DIMMs	1, 2, and 3
   Four DIMMs	All (1, 2, 3, and 4)

   Note: If you install different sized DIMMs in your Mac Pro, follow the order in the table. If the DIMM configuration you install doesn't provide optimized performance, the Memory Slot Utility should appear onscreen and recommend an improved configuration. To use the utility again, go to /System/Library/CoreServices/Memory Slot Utility.

5. Open the ejectors on DIMM slots 1, 2, and 3 and push them out to the sides. Remove the DIMMs from the slots.
6. Install the DIMMs by aligning them in the DIMM slots and pushing both ends of the DIMM down until the tabs are vertical and the ejectors snap into place.

   Note: To avoid damaging the DIMM, hold it by the corners and don't touch the gold connectors or other components.

7. Reinstall the processor tray, pushing it in until the latches are at a 45-degree angle.
8. Push the latches all the way in to close them and seat the processor tray.

In an 8-Core Mac Pro (Early 2009)​

1. Push the latches on the processor tray until they partially open.
2. Pull the latches until they open all the way and release the processor tray.
3. Remove the processor tray and lay it on a soft, clean cloth on the desk or work surface to protect the tray and avoid scratching the work surface.
4. If you install equal-size DIMMs (all 1, 2, or 4 GB) in your Mac Pro, Apple recommends that you fill the slots in the order listed in the table.

   If you have	Fill these slots	Fill these slots
   Two DIMMs	1 and 2
   Three DIMMs	1, 2, and 3
   Four DIMMs	1, 2, 5, and 6
   Six DIMMs	1, 2, 3 and 5, 6, 7
   Eight DIMMs	1, 2, 3, 4, and 5, 6, 7, 8 (all)

   Note: If you install different-size DIMMs in your Mac Pro, follow the order in the table. If the DIMM configuration you install doesn't provide optimized performance, the Memory Slot Utility should appear onscreen and recommend an improved configuration.

5. To use the utility again, go to /System/Library/CoreServices/Memory Slot Utility.
6. Install the DIMMs by aligning them in the DIMM slots and pushing both ends of the DIMM down until the tabs are vertical and the ejectors snap into place.

   Note: To avoid damaging the DIMM, hold it by the corners and don't touch the gold connectors or other components.

7. Reinstall the processor tray, pushing it in until the latches are at a 45-degree angle.
8. Push the latches all the way in to close them and seat the processor tray.

Step 4: Replace the side panel

Note: Always replace the side panel after installing components. Your Mac Pro doesn't operate properly without the side panel in place.

Important: When you replace the side panel, make sure the latch is up. Hold the side panel securely so it stays in place as you push the latch down.

1. Hold the side panel against your Mac Pro and push the latch down to secure the side panel.
2. You can attach a lock or cable through the metal loop to secure your Mac Pro. Flip the lock tab down before you close the latch.

Applicable models

Mac Pro (Early 2008)
Mac Pro (8-core)
Mac Pro (Original)

Memory specifications

This Mac Pro model has these memory specifications:

You should install FB-DIMMs in matched pairs of equal size and equal specification. Use the table below and the instructions that follow as guidelines for DIMM placement.

Removing or installing memory

Warning: Let your Mac Pro cool down for 5 to 10 minutes before you touch the internal components. The components on the memory cards may be very warm.

Step 1: Remove the side panel

1. Shut down your Mac Pro.

   Note: Always shut down your Mac Pro before opening it to avoid damaging its internal components or the components you want to install. Do not open your Mac Pro or attempt to install items inside it while it is on.

2. Wait 5 to 10 minutes to allow the internal components of your Mac Pro to cool.

   Warning: Let your Mac Pro cool down before you touch the internal components, which may be very warm.

3. Touch the metal on the outside of your Mac Pro to discharge any static electricity.

   Important: Always discharge static before you touch parts or install components inside your Mac Pro. To avoid generating static, do not move around the room until you finish installing the cards, memory, or internal storage device and replace the side panel.

4. Unplug all the cables and the power cord from your Mac Pro.

   Note: To avoid damaging internal components or the components you want to install, always unplug your Mac Pro. Don't attempt to install items while it's plugged in.

5. Hold the side panel and lift the latch on the back.
6. Remove the side panel by pulling the top away from your Mac Pro and lifting up.

   Important: Hold the side panel securely wile you remove it.

Step 2: Install or remove the memory cards

1. Using the two finger holes, pull on the memory cards to remove them, then place them on a soft, clean cloth with the DIMMs facing up.
2. On the bottom memory card, open the ejectors on the DIMM slot and push them out to the sides, and then remove the DIMM from slot 1.

   Important: When installing or removing DIMMs, don't touch the gold connectors on the DIMMs or the memory cards.

3. Reinstall the DIMM you removed on the top memory card by aligning it in DIMM slot 2, as shown in the illustration, and pushing both ends of the DIMM down until the tabs are vertical and the ejectors snap into place.
4. Install the first pair of additional DIMMs on the bottom memory card in DIMM slots 1 and 2, the slots closest to the card's gold connectors.

   Important: Always install DIMMs as matched pairs and in the order shown below.

   Move one DIMM from bottom card to top card	First pair of additional DIMMs
   Top memory card
   Bottom memory card

5. If you add a second pair of additional DIMMs, install them on the top memory card in DIMM slots 3 and 4, the last two slots.


   Second pair of additional DIMMs	Third pair of additional DIMMs
   Top memory card
   Bottom memory card

6. If you add a third pair of additional DIMMs, install them on the bottom memory card in DIMM slots 3 and 4.
7. Lay your Mac Pro down on a soft, clean cloth on the desk or work surface to avoid scratching the work surface or your Mac Pro.
8. Reinstall each memory card, pushing it straight down until it's seated in the memory slot.

Step 3: Replace the side panel

1. Stand your Mac Pro up and replace the side panel.

   Important: When you replace the side panel, make sure the latch is up. Hold the side panel securely so it stays in place as you push the latch down.

2. Hold the side panel against your Mac Pro and push the latch down to secure the side panel.
3. You can attach a lock or cable through the metal loop to secure your Mac Pro. Flip the lock tab down before you close the latch.

Learn more

Checking that your computer recognizes the new memory

1. Press the power button to turn on your Mac Pro.
2. When the Mac OS desktop appears, choose Apple (), then About This Mac and check that the reported amount of memory is correct.

If the reported memory size isn't correct, the computer may be having issues recognizing a memory module. If this happens, shut down your Mac Pro, verify the module specifications against the requirements listed above, and repeat the memory installation instructions to make sure the modules are installed correctly. If you still have issues, remove the memory and consult the support information that came with the memory, or contact the vendor who provided the memory.

Purchasing memory

When purchasing DIMMs for use in Mac computers, make sure that the memory vendor conforms to the Joint Electron Device Engineering Council (JEDEC) specification. Check with your memory vendor to ensure that the DIMMs support the correct timing modes and that the Serial Presence Detect (SPD) feature has been programmed properly, as described in the JEDEC specification.
